Description
Swarovski Objective Module: the largest objective in the system, 30-70x with ATX/STX. 74 oz.
The ATX/STX/BTX system is modular: you choose an eyepiece module (ATX angled, STX straight or BTX binocular) and an objective module (65, 85, 95 or 115 mm), and they lock together with a bayonet. You can change either part later, for example adding a 65 mm objective for backpack hunts and a 95 mm for long sessions from the truck. The 115 mm is the biggest option, made for glassing from a vehicle, a blind or a base camp, where its extra light-gathering pays off at dawn and dusk. Swarovski also makes 65, 85 and 95 mm objective modules; email us if you need a different size.
Swarovski Objective Module specs
| Module | 115 mm objective |
|---|---|
| Compatible eyepieces | ATX (angled), STX (straight), BTX (binocular) |
| Magnification | 30–70x with ATX/STX; 35x with BTX |
| Exit pupil (ATX/STX) | 3.9–1.6 mm |
| Close focus | 15.7 ft (4.8 m) |
| Length | 12 in |
| Weight | 74 oz |
| Warranty | SWAROVSKI OPTIK manufacturer’s warranty |
| Price | $3,699.00 (objective only) |
Who is the 115 mm objective for?
Hunters who glass mostly from a vehicle or fixed position and want maximum brightness and detail at 50–70x; it is heavy for backpacking.
115 mm vs 95 mm objective
Both give 30–70x. The 115 mm gathers substantially more light, which shows at high magnification and in low light; the 95 mm is lighter.
What else do I need?
An eyepiece module (ATX, STX or BTX) and a sturdy tripod rated for the combined weight of about 6.5 lb.
What’s in the box with the Swarovski Objective Module?
- 115 mm objective module
- Objective cap
Gear to pair with the Swarovski Objective Module
Swarovski Objective Module FAQ
Does the objective module work alone?
No, it must be combined with an ATX, STX or BTX eyepiece module.
How much does the 115 mm module weigh?
About 74 oz.
Do you sell the 65, 85 and 95 mm modules?
Yes on request; email sales@bestbuytronics.com.
Manuals, firmware updates and warranty registration are on the Swarovski Optik official website.
